Cylinders & Cones
Uni-Form Components Co. offers Rolled and / or Press Formed parts and cylinders as part of our efforts to meet all of your forming needs. For additional benefits, pair Uni-Form Components Cylinders or Cones with our heads for a quicker and easier fit up.
Rolled / Pressed Components:
- Arc Segments
- Baffles
- Cones
- Cylinders
- Half Shells
- Re-pads
- Tray Rings
Capacity:
- Thickness: Up to 12”
- Diameters: Up to 240”
- Width: Up to 144”
- 4 Plate Rolls capable of rolling plate both Cold or Hot
- Multiple Cold and Hot Forming Presses from 350 up to 2,500 tons
Cones and Cylinders are available with Tack Welded or Fully Welded Seams with 100% Radiography and Partial Data Reports. (additional on-site NDE available)
Arc Segment
- Diameter: 12" RAD - 600" RAD
- Thickness: 3/16" - 8-3/4"
Toriconical
- Diameter 6" - 216"
- Thickness: 3/16" - 9-1/2"
Conical
- Diameter: 6" - 216"
- Thickness: 3/16" - 9 1/2"
Cylinder
- Diameter: 6" - 300"
- Thickness: 3/16" - 9 1/2"
